Blister packaging machine

SMT-PX500C

SMT-PX500C Automatic spiral wound gasket winding machine is our newest design, it has the best automatic function all over China.
The automatic functions of this machine include PLC size controlling, with SS strip forming roller, Automatic spot welding, Automatic SS strip cutting (new).

SMT-PX2000D-2

PLC size control,
with automatic cutter,
continuous fast processing.

SMT-PX-2500C

SMT-PX-2500C is improved style based on SMT-PX-2500B, this style include PLC size control system and automatic spot welding; SS hoop forming parts for option.
Suitable for spiral wound gasket ID 300mm to 3200mm with or without inner ring.
Gasket thickness 4.5mm (also suitable for 3.2mm, 6.4mm and 7.2mm after changing roller parts, V shape winding or W shape winding)

SMT-PX-300C

This is our new design style automatic winding machine for SWG. Producing range diameter 25-500mm.
Both Manual and Automatic mode.
Can use both pre-formed SS strip in pancake or 20-25kgs spool of flat strip. Standard package including models for 1"-10" 150# SWG with or without inner ring.

SMT-PX1000D-2

Bending Ring width:6mm--20mm, ring size:120-1000mm;
PLC touch screen setting length control, Automatic cutting.

SMT-PX1200S

This machine was designed to winding gasket from 150 to 1200mm diameter spiral wound gasket.
Both manual model and automatic model available.
Can winding any shape of SWG.

SMT-PX2000N

Milling the outer edge of spiral wound gasket inner ring into V shape

PX1250

This machine was designed to polish the surface of the spiral wound gasket inner and outer ring

SMT-5213

SMT-5213 style is used to make Kammprofile gasket in a very fast and convenient way.
Kammprofile pitch both 1.0 and 1.5mm available. HSS saw blades and Alloy blade in set for option.

SMT-5210

SMT-5210 Slitting machine is used to slit spiral wound gasket hoop (Stainless steel strip) in flat shape. The widest SS before slitting is 120mm, thickness 0.1-0.3mm, slitting size 3.6 4.8 5.0 8.0 10.0MM width for option.
One machine can produce more than 1000kgs of strip per day.
