SMT-PX500C Automatic spiral wound gasket winding machine is our newest design, it has the best automatic function all over China.
The automatic functions of this machine include PLC size controlling, with SS strip forming roller, Automatic spot welding, Automatic SS strip cutting (new).

PLC size control,
with automatic cutter,
continuous fast processing.

SMT-PX-2500C is improved style based on SMT-PX-2500B, this style include PLC size control system and automatic spot welding; SS hoop forming parts for option.
Suitable for spiral wound gasket ID 300mm to 3200mm with or without inner ring.
Gasket thickness 4. 5mm (also suitable for 3. 2mm, 6. 4mm and 7. 2mm after changing roller parts, V shape winding or W shape winding)

This is our new design style automatic winding machine for SWG. Producing range diameter 25-500mm.
Both Manual and Automatic mode.
Can use both pre-formed SS strip in pancake or 20-25kgs spool of flat strip. Standard package including models for 1"-10" 150# SWG with or without inner ring.

Bending Ring width:6mm--20mm, ring size:120-1000mm;
PLC touch screen setting length control, Automatic cutting.

This machine was designed to winding gasket from 150 to 1200mm diameter spiral wound gasket.
Both manual model and automatic model available.
Can winding any shape of SWG.

This machine was designed to polish the surface of the spiral wound gasket inner and outer ring

SMT-5218 Blister packaging machine is used to vacuum package small gaskets in a convenient , clean and beautiful way.

Different flim width as per customs request.

Precision stainless steel slot U shims, mostly used for wheel alignment.
Thickness: 0. 05mm to 3mm
Handle case package available.

Machining precision:
Flatness: 2um/100mm
Parallelism: 1um/100mm
Roughness: Ra=0. 2 (lapping) Ra= 0. 01 (polishing)
Finish can achieve mirror face

This type of flat and big spool SS strip is suitable to use on our SMT-PX300C and SMT-PX500C Automatic winding machine.
